6
Connect the wires from the camera to the main wires using the supplied wire nuts:
Connect the copper wire (ground) from the camera to the main ground wire.
Connect the white wire (neutral) from the camera to the main neutral wire.
Connect the black wire (live) from the camera to the main live wire.
Route the connected wires through the mounting place so they are secure inside the
junction box.
Connect the camera to the mounting plate by inserting the mounting screw through the
center of the camera and tighten until secure.
Apply a bead of silicone around the perimeter of the junction box where it contacts the
installation surface to add an extra layer of waterproofing.
Adjust the angles of the floodlights and the camera lens to the desired locations. Ensure
the PIR detector is parallel to the ground to ensure optimal detection.
