3
No. Description
2 10 Mbps/100 Mbps/1000 Mbps self-adaptive uplink Ethernet port.
3 1000 Mbps self-adaptive uplink optical port.
4
Optical port connection or data transmission status indicator (Link/Act).
●
On: Connected to device.
●
Off: Not connected to device.
●
Flashes: Transmitting data (1000 Mbps).
5
Power indicator.
●
On: Power on.
●
Off: Power off.
6
Uplink Ethernet port connection status indicator (Link).
●
On: Connected to device.
●
Off: Not connected to device.
7
Uplink Ethernet port data transmission status indicator (Act).
●
Flashes: Transmitting data (10 Mbps/100 Mbps/1000 Mbps).
●
Off: No data transmission.
8
PoE Ethernet ports status indicator.
●
On: Powered by PoE.
●
Off: Not powered by PoE.
9
Single-port connection or data transmission status indicator (Link/Act).
●
On: Connected to device.
●
Off: Not connected to device.
●
Flashes: Transmitting data.
10
10 Mbps/100 Mbps or 10 Mbps/100 Mbps/1000 Mbps self-adaptive Ethernet
ports.
11
Uplink Ethernet port connection status indicator (Link).
●
On: Connected to device.
●
Off: Not connected to device.
12
Uplink Ethernet port data transmission status indicator (Act).
●
Flashes: Transmitting data (10 Mbps/100 Mbps/1000 Mbps).
●
Off: No data transmission.
2.2 Side Panel
The following figures are for reference only, and might differ from the actual product.
