Local Configurations 134
Figure 5-96
Click Apply to save the settings. Step 6
If you have configured the snapshot schedule, the configuration has been
completed.
If you have not configured the snapshot schedule, see "5.1.4.10 Configuring
Snapshot Storage Schedule."
5.8.1.2 Configuring Event Triggered Snapshot
Select Main Menu > CAMERA > ENCODE > Snapshot. Step 1
The Snapshot interface is displayed.
In the Mode list, select Event, and then configure other parameters. See Figure 5-97. Step 2
