Local Configurations 140
Figure 5-103
No.
Function
Description
1
Display Window
Display the searched recorded video or picture. It supports playing
in single-channel, 4-channel, 9-channel, and 16-channel
simultaneously.
When playing back in a single channel mode, hold down the left
mouse button to select the area that you want to enlarge. The area
is enlarged after the left mouse button is released. To exit the
enlarged status, right-click on the image.
2
Playback
Controls Bar
Playback control buttons. For details about the control buttons, see
"5.9.3.1 Introducing Playback Controls."
