Dahua DH-XVR5116HE-X

Local Configurations 243
Figure 5-205
Configure the settings for the UPnP parameters. See Table 5-65. Step 2
Parameter
Description
PAT
Enable the UPnP function.
Status
Indicates the status of UPnP function.
Offline: Failed.

Online: Succeeded.

LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address
automatically without performing any configurations.
WAN IP
Enter IP address of router on the WAN.
After mapping succeeded, the system obtains IP address
automatically without performing any configurations.
