Table 2-1 Camera structure description
1 Protective cover 3 Lens
2 Illuminator — —
2.3.2 Rear Panel
Figure 2-5 Rear panel structure
Table 2-2 Description of rear panel structure
2.4 Cable Connection
Two cable connection methods are available, and the actual product shall prevail.
Figure 2-6 Cable connection (1)
