User’s Manual
39
Step 3 Click Confirm.
4.5.1.5 Extra Device
4.5.1.5.1 Extra Device Status
You can view the type, number, status and match status of extra device.
If it is connected to vehicle detector and CarDetect is selected as Protocol from Setup > ITC >
Detection RS485/IO, then it can detect whether the associated information and status of
vehicle detector is normal.
Select Setup > ITC > Extra Device > Extra Device Status. The Extra Device Status interface
is displayed.
Figure 4-40 Extra device status
4.5.1.5.2 Spotlight
This section provides guidance on configuring light array and output mode of flashing light.
Step 1 Select Setup > ITC > Extra Device > Spotlight.
Figure 4-41 Spotlight (white light model)
