Dahua DHI-NVR2108-8P-4KS2 User Manual

4
3 Rear Panel
Follow figures listed here for reference only. Please refer to the actual product for detailed information.
For SMART BOX series product, the front panel is shown as in Figure 3-1.
Figure 3-1
For SMART 1U series product, the front panel is shown as in Figure 3-2.
Figure 3-2
For mini 1U, compact 1U series product, the front panel is shown as in Figure 3-3.
Figure 3-3
For 1U series product, the front panel is shown as in Figure 4-4
Figure 3-4
Note

Dahua DHI-NVR2108-8P-4KS2 Specifications

General

Brand	Dahua
Model	DHI-NVR2108-8P-4KS2
Category	Network Hardware
Language	English
