Dahua HD IR Vari-focal Dome Network Camera Quick Start Guide
2 Device Installation
2.1 Install SD Card (Optional)
Note
Please install SD card if the device is equipped with SD card slot and it needs to use SD card.
Please cut off the device power before installing Micro SD card.
Step 1
Use wrench to loosen the screw on the dome cover, open dome cover.
Open protection cover and you can see SD card slot and reset button.
Step 2
Open SD card slot, adjust the direction of SD card, install the SD card well, close the SD card slot and
lock it firmly, which is shown in Figure 2-1.
Figure 2-1
Note
Long press the reset button for 10 seconds with power on if the device needs to restore factory default
setting.
2.2 Fix Device
Note
The following installation figure is for reference only; please refer to the figure according to the
actual product.
Before installation, please make sure the installation surface can at least support 3x weight of the
camera.
