3
extra stream
1(704*480@30fps)
extra stream
2(704*576@1fps)
Note:
Extra stream 2’s actual frame rate depends on device max capacity set
which can be adjusted within its range.
Video Bit Rate
H.264H: 40Kbps-8192Kbps adjustable
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, tampering, overlay.
Lens
3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record and Backup
Record Priority
Manual>Video detect>Schedule
Storage
Management
NAS storage
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP, QoS, 802.1x.
Protocol
PSIA, ONVIF
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc.
Aux
Reset
External reset button
IR light
IR distance 20~30m
General Parameter
Power
Support DC12V power or PoE.
Power
Consumption
DC 12V, 5W MAX
DC 12V, 5.5W MAX
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
70*69.9*178.4
Weight
500g（Excluding box）
Installation
Installation with the bracket.
