Dahua NVR21-S2 SERIES User Manual

267
Figure 4-158
Step 2 Click Add button, the interface is shown as below. See Figure 4-159.
Set parameters.
 Enable: Check the box to enable POS function.
 Name: Set POS name.
1. Click
2. Input POS name on the pop-up dialogue box.
3. Click OK button.
Note
The POS name shall be unique.
System max supports 64 English letters.
 Event: Set POS arm/disarm period, record channel and etc. Click Setup to go to the
interface. For detailed information, please refer to chapter 4.7.1.1 motion detect.
 Privacy：After enable this function, once the overlay information contain the privacy
character, it displays as *. For example, the privacy character is 12,56,89, the local preview and
WEB surveillance information is shown as **34**7** if the overlay information is 123456789. For
detailed information, please refer to chapter 4.7.12.1 privacy setup.
 Protocol type: The default setup is POS.
 Connection type: It is to set and NVR connection mode. It includes UDP,TCP,RS232,RS485.
After set the connection type, please click the Setup button to set the corresponding parameters.
For detailed information, please refer to chapter 4.7.12.2 connection type.
 Convert: It is to set font type.
 Overlay: It is to set overlay mode. It includes turn and roll.
