Dahua NVR2104-S2 User Manual

3
Important：
Please turn off the power before you replace the HDD.
4. Front Panel
The front panel is shown as in Figure 1.
Figure 1
Please refer to the following sheet for detailed information.
Icon
Name
Function
NET
Network status
indicator light
The red light becomes on when the network
connection is abnormal.
PWR
Power indicator
light
The red light becomes on when the power
connection is OK.
HDD
HDD status
indictor light
The red light becomes on when HDD is
abnormal.
IR
Remote control
receiver
It is to receive signal from the remote control.
5. Rear Panel
4. Turn the device upside down
and then turn the screws in
firmly.
in the chassis.
5. Fix the HDD firmly.
6. Connect the HDD cable and
power cable.
7. Put the cover in accordance
with the clip and then place the
upper cover back.
8. Secure the screws in the
rear panel and the side panel.
