Dahua NVR4416-16P-I - NVR52-16 P-I;52-8 P-I;4216-16 P-I;4208-8 P-I;4216-I Series

Device Installation 25
Figure 3-10
3.4.2 NVR52-16P-I/52-8P-I/4216-16P-I/4208-8P-I/4216-I Series
Different models have different HDD numbers. The actual product shall prevail.
Remove the four fixing screws on the rear panel.
Figure 3-11
Remove the case cover along the direction shown in the following arrow.
Figure 3-12
Match the four holes on the baseboard to place the HDD.
