Dahua Pro Series User Manual

Installation 8
Installing Camera 4.2
4.2.1 (Optional) Installing SD Card
 Please cut off the device power before installing SD card.
 Be cautious and do not mistake Micro SD card slot for reset hole. Long press the reset
button for 4 seconds–5 seconds and you will reset your Camera.
 Please check if the waterproof ring is installed properly before closing the cover, otherwise,
it will affect the waterproof performance of the device.
Installing SD card Figure 4-1
Table 4-3 Camera component list
No.
Name
No.
Name
1
Micro SD card slot
2
Reset hole

Dahua Pro Series Specifications

General

Operating Temperature	-30 °C to +60 °C (-22 °F to +140 °F)
Lens Type	Fixed or varifocal options available
Weatherproof Rating	IP67
Audio	Built-in microphone and/or audio input/output
Smart Features	Intrusion
Power Supply	12V DC, PoE (802.3af/at) (depending on model)
Image Sensor	1/2.5" CMOS
IR Distance	Up to 30m (varies by model)
Video Compression	H.265/H.264
Wide Dynamic Range (WDR)	120 dB
Intelligent Video System (IVS)	Tripwire, Intrusion
Ethernet	RJ-45 (10/100Base-T)
Ingress Protection	IP67
Storage	Micro SD card slot (up to 256 GB)
Resolution	Up to 8MP (4K)
Max. Resolution	3840 x 2160 (8MP)
