Dahua VTH1510A User Manual

Figure 1- 10 VTH15 Series AH Model
No.
Name
Note
1
Alarm port
8-ch alarm, may connect to external alarm extension
module, refer to label for details.
2
Debug port
For installation staff use only.
3
Network port
Plug in network cable.
4
Handset port
For model with handset only.
5
Power port
Connect to 2-pin plug 12V.

Dahua VTH1510A Specifications

General

Brand	Dahua
Model	VTH1510A
Category	Intercom System
Language	English
