The Add interface is displayed. See Figure 5-10.
Add single room number
8) Configure room information. See Table 5-3.
Table 5-3 Room information
Enter the information you need to differentiate each room.
The room number you planned.
If you use multiple VTH devices, the room number of the
master VTH should be "room number#0", and the room
number of the extension VTH should be "room
number#1", "room number#2", and so on.
You can have 10 extension VTH devices at most for one
master VTH.
Select public, and local is reserved for future use.
9) Click Save.
The added room number is displayed. Click to modify room information, and click
to delete a room.
Adding room number in batch
1) Configure the Unit Layer Amount, Room Amount in One Layer, First Floor Number,
and Second Floor Number according to the actual condition.
2) Click the Add at the bottom position. See Figure 5-11
