178
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
Communicatio
n Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps
Ethernet port
RS485
Communicatio
n
1 RS485 port
USB
2 USB2.0 ports(One at the front panel and one at
the rear panel)
1 USB2.0 port
and 1 USB3.0
port (One
USB2.0 port at
the front panel
and one
USB3.0 port at
the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
Model
Parameters
XVR4232AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
4M Lite/1080P@15fps/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps～4096Kbps
Bit Stream
Type
Video stream/composite stream
