199
video and multiple-channel data to
the HDMI port of the display
device.
7
Network port
100M Ethernet port
2.2.4 HCVR4104/HCVR4108C-S2/HCVR2108C-S2 Series
The HCVR4104C-S2 series rear panel is shown as below. See Figure 2- 15.
Figure 2- 15
The HCVR4108C-S2/HCVR2108C-S2 series rear panel is shown as below. See Figure
2- 16.
Figure 2- 16
Please refer to the following sheet for detailed information.
SN
Icon
Name
Note
1
GND
Ground end
2
USB2.0 port
Connect to USB storage device,
mouse, burning DVD-ROM and
etc.
