SiBE12-519 Cooling Only
Specifications 13
1.2.1 Combination Capacity
Wall Mounted Type D Series
Cooling [230V]
50Hz
Note:
1. Cooling capacity is based on 27°CDB/19°CWB (Indoor temperature), 35°CDB (Outdoor temperature).
2. The total ability of connected indoor units is up to 6.0kW.
3D049739#2
Wall Mounted Type C Series
Cooling [230V]
50Hz
Note:
1. Cooling capacity is based on 27°CDB/19°CWB (Indoor temperature), 35°CDB (Outdoor temperature).
2. The total ability of connected indoor units is up to 6.0kW.
3D049739#3
Combination
of Indoor Unit
Each Capacity (kW) Total Capacity (kW) Total Input (W) Total Current (A)
Power
Factor (%)
A room B room C room D room Rating (min~max) Rating (min~max) Rating (min~max) Rating
2.0 2.00 — — — 2.00 1.20~2.40 610 340~740 2.8 1.9~3.4 94
2.5 2.50 — — — 2.50 1.20~3.00 760 340~1020 3.5 1.9~4.7 94
3.5 3.15 — — — 3.15 1.20~3.60 1120 340~1440 5.1 1.9~6.5 95
2.0+2.0 1.90 1.90 — — 3.80 1.50~4.10 1190 400~1460 5.5 2.2~6.7 94
2.0+2.5 1.80 2.10 — — 3.90 1.50~4.10 1210 400~1460 5.6 2.2~6.7 94
2.0+3.5 1.70 2.20 — — 3.90 1.50~4.20 1210 400~1490 5.6 2.2~6.8 94
2.5+2.5 1.95 1.95 — — 3.90 1.50~4.20 1210 400~1490 5.6 2.2~6.8 94
2.5+3.5 1.75 2.15 — — 3.90 1.50~4.20 1210 400~1490 5.6 2.2~6.8 94
Combination
of Indoor Unit
Each Capacity (kW) Total Capacity (kW) Total Input (W) Total Current (A)
Power
Factor (%)
A room B room C room D room Rating (min~max) Rating (min~max) Rating (min~max) Rating
2.0 2.00 — — — 2.00 1.20~2.40 620 340~750 2.9 1.9~3.4 94
2.5 2.50 — — — 2.50 1.20~3.00 770 340~1030 3.6 1.9~4.7 94
3.5 3.15 — — — 3.15 1.20~3.60 1140 340~1460 5.2 1.9~6.6 95
2.0+2.0 1.90 1.90 — — 3.80 1.50~4.10 1210 400~1490 5.6 2.2~6.9 94
2.0+2.5 1.80 2.10 — — 3.90 1.50~4.10 1240 400~1490 5.7 2.2~6.9 94
2.0+3.5 1.70 2.20 — — 3.90 1.50~4.20 1240 400~1520 5.7 2.2~6.9 94
2.5+2.5 1.95 1.95 — — 3.90 1.50~4.20 1240 400~1520 5.7 2.2~6.9 94
2.5+3.5 1.75 2.15 — — 3.90 1.50~4.20 1240 400~1520 5.7 2.2~6.9 94
