Removal of Compressor
Si121174
30
Removal Proc
edure
9.
Removal of Compre
ssor
P
r
o
ce
du
r
e
Warning
Be sure to wait f
or 10 minutes or more after
turni
ng off all
power
supplies before d
isassembling work.
Step
Procedure
Points
1
Remove the terminal
cover.
2
Disconnect t
he
compressor l
ead wires
.
3
Detach the ov
erload
protec
tor.
(R12914)
T
erminal cover
V(yellow)
U(red)
W(blue)
(R5602)
(R12916)
Overload protector
(R5604)
31
33
