Wireless Remote
Controller
Address
Factory set is 1. Change the wireless remote controller address setting by the following steps, if
necessary.
1. Hold down button and /TEST button at the same time for at least 4 seconds to enter the
field setting mode. (SETTING is indicated on the display).
Press FAN button and select display setting ( or ). Each time the button is pressed, the
display switches between and .
2. Press button and button to set the address.
Address can be set from 1 ~ 6, but set it to 1 ~ 3 and to same address as the transmitter board.
The transmitter board does not work with address 4 ~ 6.
3. Press RESERVE button to confirm the setting.
4. Hold down /TEST button to quit the field setting mode and return to the normal display.
Field setting mode
Address
Multiple setting
(R14401)
