Daikin 4MXL-T Series

SiUS121827E Specifications
Part 2 Specifications 23
1. Specifications
1.1 RA Indoor Unit
Model FTXR09TVJUW FTXR09TVJUWS
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 9 kBtu/h Class 9 kBtu/h Class
Front Panel Color White Silver
Airflow Rates H
cfm
(m
3
/min)
272 (7.7) 346 (9.8) 272 (7.7) 346 (9.8)
M 208 (5.9) 258 (7.3) 208 (5.9) 258 (7.3)
L 162 (4.6) 201 (5.7) 162 (4.6) 201 (5.7)
SL 134 (3.8) 117 (3.3) 134 (3.8) 117 (3.3)
Fan Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.07 - 0.07 0.13 - 0.12 0.07 - 0.07 0.13 - 0.12
Power Consumption (Rated) W 13 - 13 26 - 26 13 - 13 26 - 26
Power Factor (Rated) % 89.2 - 80.7 96.2 - 94.2 89.2 - 80.7 96.2 - 94.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212)
Packaged Dimensions (H × W × D) in. (mm) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389)
Weight (Mass) Lbs (kg) 27 (12) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 36 (16) 36 (16)
Sound Pressure
Level
H / M / L / SL
dB(A) 38 / 32 / 25 / 19 41 / 34 / 28 / 19 38 / 32 / 25 / 19 41 / 34 / 28 / 19
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) φ 11/16 (φ 18) φ 11/16 (φ 18)
Drawing No. 3D120044 3D120044
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Model FTXR12TVJUW FTXR12TVJUS
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 12 kBtu/h Class 12 kBtu/h Class
Front Panel Color White Silver
Airflow Rates H
cfm
(m
3
/min)
335 (9.5) 395 (11.2) 335 (9.5) 395 (11.2)
M 219 (6.2) 290 (8.2) 219 (6.2) 290 (8.2)
L 169 (4.8) 226 (6.4) 169 (4.8) 226 (6.4)
SL 131 (3.7) 131 (3.7) 131 (3.7) 131 (3.7)
Fan Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.13 - 0.12 0.19 - 0.17 0.13 - 0.12 0.19 - 0.17
Power Consumption (Rated) W 26 - 26 38 - 38 26 - 26 38 - 38
Power Factor (Rated) % 96.1 - 94.2 96.1 - 97.1 96.1 - 94.2 96.1 - 97.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212)
Packaged Dimensions (H × W × D) in. (mm) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389)
Weight (Mass) Lbs (kg) 27 (12) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 36 (16) 36 (16)
Sound Pressure
Level
H / M / L / SL
dB(A) 45 / 34 / 26 / 20 45 / 37 / 29 / 20 45 / 34 / 26 / 20 45 / 37 / 29 / 20
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) φ 11/16 (φ 18) φ 11/16 (φ 18)
Drawing No. 3D120044 3D120044
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
