Wireless Remote Controller Receiver for FDMQ series SiUS121827E
52 Part 3 Printed Circuit Board Connector Wiring Diagram
4. Wireless Remote Controller Receiver for FDMQ
series
4.1 BRC082A43
Wired Remote
Controller PCB
1) SS1 MAIN/SUB setting switch
∗ Refer to page 268 for details.
2) SS2 Address setting switch
∗ Refer to page 268 for details.
3) P1, P2 Terminal for indoor unit control PCB (A1P)
SS1
P2 P1
3P156152-1
SS2
To Next Page
