Outdoor Unit SiUS121827E
290 Part 8 Appendix
Note(s)
3. Outdoor Unit
5MXS48TVJU
PCB1: Main PCB
PCB2: Service monitor PCB
Refer to page 54 for Printed Circuit Board Connector Wiring Diagram.
3D118022
