Daikin 4MXL-T Series

Specifications SiUS121827E
26 Part 2 Specifications
Model CTXS07LVJU
Cooling Heating
Power Supply Phase 1 φ
Hz, V 60 Hz, 208 - 230 V
Rated Capacity 7 kBtu/h Class
Front Panel Color White
Airflow Rates H
cfm
(m
3
/min)
332 (9.4) 350 (9.9)
M 261 (7.4) 290 (8.2)
L 194 (5.5) 233 (6.6)
SL 145 (4.1) 219 (6.2)
Fan Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.09 - 0.08 0.11 - 0.10
Power Consumption (Rated) W 18 - 18 21 - 21
Power Factor (Rated) % 96.2 - 97.8 91.8 - 91.3
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366)
Weight (Mass) Lbs (kg) 20 (9)
Gross Weight (Gross Mass) Lbs (kg) 29 (13)
Sound Pressure
Level
H / M / L / SL
dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power Level dB 54 54
Heat Insulation Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5)
Drain in. (mm) φ 5/8 (φ 16.0)
Drawing No. 3D075490
Notes 1. SL: The quiet fan level of the airflow rate setting.
Model FTXS09LVJU FTXS12LVJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
Front Panel Color White White
Airflow Rates H
cfm
(m
3
/min)
381 (10.8) 420 (11.9) 403 (11.4) 438 (12.4)
M 279 (7.9) 321 (9.1) 307 (8.7) 335 (9.5)
L 194 (5.5) 233 (6.6) 205 (5.8) 240 (6.8)
SL 145 (4.1) 219 (6.2) 155 (4.4) 212 (6.0)
Fan Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.09 - 0.08 0.11 - 0.10 0.13 - 0.12 0.14 - 0.13
Power Consumption (Rated) W 18 - 18 21 - 21 26 - 26 28 - 28
Power Factor (Rated) % 96.2 - 97.8 91.8 - 91.3 96.2 - 94.2 96.2 - 93.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366)
Weight (Mass) Lbs (kg) 20 (9) 22 (10)
Gross Weight (Gross Mass) Lbs (kg) 29 (13) 31 (14)
Sound Pressure
Level
H / M / L / SL
dB(A) 41 / 33 / 25 / 22 42 / 35 / 28 / 25 45 / 37 / 29 / 23 45 / 39 / 29 / 26
Sound Power Level dB 57 58 61 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) φ 5/8 (φ 16) φ 5/8 (φ 16)
Drawing No. 3D075491A 3D075492A
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
