Daikin AGZ030E - Set Points (Continued)

UnIT ConTroller operaTIon
www.DaikinApplied.com 47 IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS
Set Points
Set points are initially set to the values in the Default column,
and can be adjusted to any value in the Range column. Set
points are stored in permanent memory. If an option is not
available on a specic model size, the respective set point will
not be needed and therefore not be visible.
Basic unit conguration set points will require the unit to be
off in order to make a change and then require rebooting the
controller in order to apply a change.
Table 38: Unit Level Set Point Defaults and Ranges
Description Default Range
Basic Unit Conguration
Unit Model AGZ000??? Based on Unit Model Conguration
Condenser Type Not Set Not Set Tube and Fin, Microchannel
Expansion Valve Type Not Set Not Set., Thermal, Electronic
Condenser Fan VFD Conguration None None, 1/cir, 2/cir
Power Connection Conguration Single Point Single Point, Multi Point
Mode/Enabling
Unit Enable Enable Disable, Enable
Control source Local Local, Network
Available Modes Cool Cool, Cool w/Glycol, Cool/Ice w/Glycol, Ice, Test
Staging and Capacity Control
Cool LWT 1 7°C (44.6°F) See Dynamic Set Point Ranges
Cool LWT 2 7°C (44.6°F) See Dynamic Set Point Ranges
Ice LWT 4.4°C (39.9°F) -9.5 to 4.4 °C (14.9 to 39.9 °F)
Startup Delta T 5.6°C (10.1°F) 0.6 to 8.3 °C (1.1 to 14.9 °F)
Shut Down Delta T 0.3°C (0.5°F) 0.3 to 1.7 °C (0.5 to 3.1 °F)
Stage Up Delay 240 sec 120 to 480 sec
Stage Down Delay 30 sec 20 to 60 sec
Stage Delay Clear No No, Yes
Max Pulldown Rate 0.6°C/min (1.1°F/min) 0.1 to 2.7°C/min (0.2 to 4.9°F/min)
Full Capacity Evap Delta T 8.9 °C (16°F) 3.3 to 8.9 °C (5.9 to 16 °F)
Variable Evaporator Flow No No, Yes
Ice TimCycle Delay 12 1-23 hours
Clear Ice Timer No No,Yes
RapidRestore Disable Disable, Enable
Rapid Restore Max Power Off 15 seconds 15 ro 180 seconds
Evaporator Pump Control
Evap Pump Control Conguration #1 Only #1 Only, #2 Only, Auto, #1 Primary, #2 Primary
Evap Recirc Timer 90 15 to 300 seconds
Evap Pump 1 Run Hours 0 0 to 999999 hours
Evap Pump 2 Run Hours 0 0 to 999999 hours
Power Conservation and Limits
LWT Reset Enable Disable Disable, Enable
Demand Limit Enable Disable Disable, Enable
High IPLV Mode Disable Disable, Enable
IPLV Condensing Target 23.89°C (75°F) 21.11 to 32.22°C (70 to 90°F)
Sound Reduction Mode
Sound Reduction Enable Disable Disable, Enable
Sound Reduction Priority Capacity Sound, Capacity
Sound Reduction Fan Speed Limit 50% 50%, 60%, 70%, 80%, 90%
Monday Start Time 22:00 00:00 to 23:00
Monday Duration 12 hrs 0 to 24 hrs
Tuesday Start Time 22:00 00:00 to 23:00
Tuesday Duration 12 hrs 0 to 24 hrs
Wednesday Start Time 22:00 00:00 to 23:00
Wednesday Duration 12 hrs 0 to 24 hrs
Thursday Start Time 22:00 00:00 to 23:00
Thursday Duration 12 hrs 0 to 24 hrs
Friday Start Time 22:00 00:00 to 23:00
Friday Duration 12 hrs 0 to 24 hrs
Saturday Start Time 22:00 00:00 to 23:00
