refrIgeranT Charge
refrIgeranT Charge
Table 6: Refrigerant Charge - Microchannel Units
Unit
Models
Microchannel Coil Unit Operating Charge - lbs (kg)
Replaceable Core Filter Drier Sealed Filter Drier
Circuit 1 Circuit 2 Circuit 1 Circuit 2
030E 17 (7.7) 17 (7.7) 15 (16.8) 15 (16.8)
035E 16 (7.3) 16 (7.3) 14 (6.4) 14 (6.4)
040E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
045E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
050E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
055E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
060E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
065E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
070E 23 (10.5) 23 (10.5) 21 (9.5) 21 (9.5)
075E 46 (20.9) 46 (20.9)
080E 46 (20.9) 46 (20.9)
090E 48 (21.8) 48 (21.8)
100E 49 (22.3) 49 (22.3)
110E 64 (29.1) 64 (29.1)
120E 65 (29.5) 65 (29.5)
130E 65 (29.5) 65 (29.5)
140E 76 (34.5) 76 (34.5)
150E 76 (34.5) 76 (34.5)
161E 78 (35.4) 78 (35.4)
170E 80 (36.3) 80 (36.3)
180E 80 (36.3) 80 (36.3)
190E
90 (40.9) 90 (40.9)
210E
94 (42.7) 94 (42.7)
225E 110 (49.9) 110 (49.9)
240E 114 (51.8) 114 (51.8)
