eleCTrICal daTa
www.DaikinApplied.com 39 IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS
Table 18: Electrical Data - Multiple Point (60/50 Hz)
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Frequency
Multiple Point Field Data - Circuit #1 Multiple Point Field Data - Circuit #2
Ratings Lug Range Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
MCA RFS MFS Power Block
Disconnect
Switch
030E
208V/60 78 100 100 (1) 14-2/0 (1) 12-1/0 78 100 100 (1) 14-2/0 (1) 4-300MCM
230V/60 78 100 100 (1) 14-2/0 (1) 12-1/0 78 100 100 (1) 14-2/0 (1) 4-300MCM
380V/60 46 60 60 (1) 14-2/0 (1) 12-1/0 46 60 60 (1) 14-2/0 (1) 12-1/0
460V/60 39 50 50 (1) 14-2/0 (1) 12-1/0 39 50 50 (1) 14-2/0 (1) 12-1/0
575V/60 34 40 45 (1) 14-2/0 (1) 12-1/0 34 40 45 (1) 14-2/0 (1) 12-1/0
400V/50 40 50 50 (1) 14-2/0 (1) 12-1/0 40 50 50 (1) 14-2/0 (1) 12-1/0
035E
208V/60 82 100 110 (1) 14-2/0 (1) 4-300MCM 88 110 110 (1) 14-2/0 (1) 4-300MCM
230V/60 82 100 110 (1) 14-2/0 (1) 4-300MCM 88 110 110 (1) 14-2/0 (1) 4-300MCM
380V/60 44 60 60 (1) 14-2/0 (1) 12-1/0 56 70 70 (1) 14-2/0 (1) 12-1/0
460V/60 39 50 50 (1) 14-2/0 (1) 12-1/0 42 50 50 (1) 14-2/0 (1) 12-1/0
575V/60 32 40 40 (1) 14-2/0 (1) 12-1/0 35 45 45 (1) 14-2/0 (1) 12-1/0
400V/50 40 50 50 (1) 14-2/0 (1) 12-1/0 44 60 60 (1) 14-2/0 (1) 12-1/0
040E
208V/60 88 110 110 (1) 14-2/0 (1) 4-300MCM 88 110 110 (1) 14-2/0 (1) 4-300MCM
230V/60 88 110 110 (1) 14-2/0 (1) 4-300MCM 88 110 110 (1) 14-2/0 (1) 4-300MCM
380V/60 56 70 70 (1) 14-2/0 (1) 12-1/0 56 70 70 (1) 14-2/0 (1) 12-1/0
460V/60 42 50 50 (1) 14-2/0 (1) 12-1/0 42 50 50 (1) 14-2/0 (1) 12-1/0
575V/60 35 45 45 (1) 14-2/0 (1) 12-1/0 35 45 45 (1) 14-2/0 (1) 12-1/0
400V/50 44 60 60 (1) 14-2/0 (1) 12-1/0 44 60 60 (1) 14-2/0 (1) 12-1/0
045E
208V/60 120 150 150 (1) 14-2/0 (1) 4-300MCM 120 150 150 (1) 14-2/0 (1) 6-350MCM
230V/60 120 150 150 (1) 14-2/0 (1) 4-300MCM 120 150 150 (1) 14-2/0 (1) 6-350MCM
380V/60 62 80 80 (1) 14-2/0 (1) 12-1/0 62 80 80 (1) 14-2/0 (1) 12-1/0
460V/60 48 60 60 (1) 14-2/0 (1) 12-1/0 48 60 60 (1) 14-2/0 (1) 12-1/0
575V/60 39 50 50 (1) 14-2/0 (1) 12-1/0 39 50 50 (1) 14-2/0 (1) 12-1/0
400V/50 49 60 60 (1) 14-2/0 (1) 12-1/0 49 60 60 (1) 14-2/0 (1) 12-1/0
050E
208V/60 127 150 175 (1) 14-2/0 (1) 6-350MCM 127 150 175 (1) 14-2/0 (1) 6-350MCM
230V/60 127 150 175 (1) 14-2/0 (1) 6-350MCM 127 150 175 (1) 14-2/0 (1) 6-350MCM
380V/60 69 90 90 (1) 14-2/0 (1) 12-1/0 69 90 90 (1) 14-2/0 (1) 12-1/0
460V/60 58 70 80 (1) 14-2/0 (1) 12-1/0 58 70 80 (1) 14-2/0 (1) 12-1/0
575V/60 51 60 70 (1) 14-2/0 (1) 12-1/0 51 60 70 (1) 14-2/0 (1) 12-1/0
400V/50 56 70 70 (1) 14-2/0 (1) 12-1/0 56 70 70 (1) 14-2/0 (1) 12-1/0
055E
208V/60 127 150 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
230V/60 127 150 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
380V/60 69 90 90 (1) 14-2/0 (1) 12-1/0 85 110 110 (1) 14-2/0 (1) 4-300MCM
460V/60 58 70 80 (1) 14-2/0 (1) 12-1/0
66 80 90 (1) 14-2/0 (1) 12-1/0
575V/60 51 60 70 (1) 14-2/0 (1) 12-1/0 59 70 80 (1) 14-2/0 (1) 12-1/0
400V/50 56 70 70 (1) 14-2/0 (1) 12-1/0 68 80 90 (1) 14-2/0 (1) 12-1/0
060E
208V/60 137 175 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
230V/60 137 175 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
380V/60 85 110 110 (1) 14-2/0 (1) 4-300MCM 85 110 110 (1) 14-2/0 (1) 4-300MCM
460V/60 66 80 90 (1) 14-2/0 (1) 12-1/0 66 80 90 (1) 14-2/0 (1) 12-1/0
575V/60 59 70 80 (1) 14-2/0 (1) 12-1/0 59 70 80 (1) 14-2/0 (1) 12-1/0
400V/50 68 80 90 (1) 14-2/0 (1) 12-1/0 68 80 90 (1) 14-2/0 (1) 12-1/0
