opTIonal loW ambIenT fan Vfd
www.DaikinApplied.com 89 IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS
Table 81: Alarm Content
State Content
Illuminated When the drive detects an alarm or error
Flashing
When an alarm occurs
When an oPE is detected
When a fault or error occurs during Auto-Tuning
Off Normal operation (no fault or alarm)
Table 82: LO/RE LED and RUN LED Indictors
LED Lit
Flashing
Slowly
Flashing Quickly Off
LO/RE
When the operator
is selected for Run
command and
frequency reference
control (LOCAL)
-- --
When a device other than
the operator is selected for
Run command and frequency
reference control (REMOTE)
RUN During run
During
deceleration
to stop
When a Run
command
is input and
frequency
reference is
0 Hz
While the drive was set to LOCAL, a Run
command was entered to the input terminals
then the drive was switched to REMOTE.
During stop
A Run command was entered via the input
terminals while the drive was not in the Drive
Mode.
During deceleration when a Fast Stop
command was entered.
The drive output is shut of by the Safe Disable
function.
The STOP key was pressed while drive was
running in REMOTE.
The drive was powered up with b1-17 = 0
(default) while the Run command was active.
