14 Technical data
Installer reference guide
113
ERHQ+ERLQ011~016 + EHBH/X11+16CB
Daikin Altherma – Low temperature split
4P384974-1 – 2015.01
Heating only type Reversible type
Indoor units EHBH11+16/EHVH11+16 EHBX11+16/EHVX11+16
Outdoor units ERHQ011BAV3 ERHQ014BAV3 ERHQ016BAV3 ERHQ011BAV3 ERHQ014BAV3 ERHQ016BAV3
Night quiet -
Heating
Sound
pressure
(d)
42dBA 42dBA 43dBA 42dBA 42dBA 43dBA
Night quiet -
Cooling
Sound
pressure
(d)
— 45dBA 45dBA 46dBA
Refrigerant
Type R410A
Charge 2.7kg
Control Expansion valve (electronic type)
Nr. of circuits 1
Refrigerant oil
Type Daphne FVC68D
Charged volume 1.5l
Piping connections
Liquid Quantity 1
Type Flare connection
Diameter (OD) Ø9.52mm
Gas Quantity 1
Type Flare connection
Diameter (OD) Ø15.9mm
Drain Quantity 3
Type Hole
Diameter (OD) Ø26mm
Piping length Minimum 3m
Maximum 75m
Equivalent 95m
Chargeless 10m
Additional refrigerant charge See "To determine the additional refrigerant amount"
Maximum height difference
between outdoor unit and indoor
unit
30m
Equivalent height difference —
Maximum interunit level
difference
—
Heat insulation Both liquid and gas pipe
Defrost method Pressure equalising
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter controlled
Capacity control (%) —
Safety devices High pressure switch / Fan motor thermal protector / Fuse
Standard accessories 1 installation manual / 2 tie wraps
(a) See operation range drawing.
(b) Range increase by support backup heater.
(c) Range increase by support booster heater.
(d) The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value depending on the distance and
acoustic environment. Refer to the sound spectrum drawing for more information.
Electrical specifications: ERHQ_V3
Heating only type Reversible type
Indoor units EHBH11+16/EHVH11+16 EHBX11+16/EHVX11+16
Outdoor units ERHQ011BAV3 ERHQ014BAV3 ERHQ016BAV3 ERHQ011BAV3 ERHQ014BAV3 ERHQ016BAV3
Power supply
Name V3
Phase 1~
Frequency 50Hz
Voltage 230V
