OPERATION
■
Setting SIMPLE & MULTI 7 DAY TIMER using copy mode
●
A setting can be copied to the setting for the next day.
1
Press
“
button”.
●
Press the button and select the program number of
the desired day of the week to copy.
“
” : blinks.
2
Press “ button”.
●
“
” is displayed on the LCD.
3
Press “ button” for at least
4 seconds.
●
The timer setting is copied to the setting for the next day.
●
Repeat using the enter button if you want to copy to
other days of the week.
4
Press “ button”.
●
“
” : blinks.
5
Press
“
button”.
●
Once you have completed the copy mode settings
press the “
button” to return to normal
operation mode.
NOTE
●
All S. 7 DAY TIMER settings also apply to M. 7 DAY TIMER.
●
For the timer setting, up to two items per day and up to 14 items per week can be set.
●
Ensure to set both the on and off timer for correct time clock operation.
●
Incomplete settings will be entered if the “
button” is pressed before all the settings are done.
To abort the settings without entering them, press the “
button”.
●
Turning the breaker off, power outages, and other similar events may render operation of the indoor
unit’s internal clock inaccurate. Reset the clock. (page 4.)
●
If an incorrect setting is made or you accidentally skip a setting item, use the “
button” to scroll
through the setting items until the required setting item is displayed.
