OPERATION
You can register a name for each zone and temperature sensor.
When you switch the zone or temperature sensor, the registered name will be displayed.
■
To register the name
1
Press
“
button” for at least
4 seconds.
“
” is displayed on the LCD.
Each time the “
button” is pressed, the display
will shift to the next zone.
“
” blinks.
2
Press “ , button” to enter
a character.
to to to blank
3
Press “ button”.
The cursor moves to the next digit.
Repeat step 2 and step 3 to set the name.
4
Press “ button”.
The setting is fixed and the display shifts to the next
zone.
Each time the “
button” is pressed, the display
will shift to the next zone.
To complete the name change, press “
button”.
“
” blinks.
Name registration
