2. BEFORE INSTALLATION
2-1 ACCESSORIES
Check if the following accessories are included with your option kit.
2-2 NOTE TO THE INSTALLER
• Be sure to instruct the customer how to properly operate the system showing him/her the attached opera-
tion manual.
3. REMOTE CONTROLLER INSTALLATION
¢Installing wireless remote controller²
• Do not throw the remote controller or impose large shocks. Also, do not store where it may be exposed to
moisture or direct sunlight.
• When operating, point the transmitting part of the remote controller in the direction of the receiver.
•
The direct transmitting distance of the remote controller is approximately 7 meters.
•
The signal cannot be transmitted if something (e.g. curtains) blocks the receiver and the remote controller.
Name
Receiver
(3) Relay
harness - long
(4) Relay
harness - short
Wireless
remote
controller
Screw
(1) Light receiver
assembly
(2) Transmission
PC-board
Quantity
1 pc. 1 pc. 1 pc. 1 pc. 1 pc. 2 pcs.
Shape
Name
Remote controller
holder
(5) Unit No.
nameplate
(6) Control panel
(with label)
Dry cell battery
LR03 (AM4)
(7) Clamp
Quantity
1 pc. 1 pc. 1 pc. 2 pcs. 1 pc.
Shape
Name Sealing material (8)
Operation manual
Installation manual
Quantity
1pc. 1 pc. 1 pc.
Shape
