Daikin CDKD35CVM User Manual

Specifications Si12-411A
26 Specifications
50Hz, 230V
Notes:
1. The operating sound is based on the rear side suction inlet and the external static pressure 40 Pa.
Operating sound for under side suction inlet:[operating sound for rear side suction inlet ]+5 dB.
However, when installation to which the external static pressure becomes low is carried out,
5 dB or more may go up.
Model CDKS25CVMB CDKS35CVMB
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color
——
Air Flow Rates
m³/min
(cfm)
H 9.5 (335) 10.0 (353)
M 8.8 (311) 9.3 (328)
L 8.0 (282) 8.5 (300)
SL 6.7 (237) 7.0 (247)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.47 0.47
Power Consumption (Rated) W 100 100
Power Factor % 92.5 92.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 200×900×620 200×900×620
Packaged Dimensions (H×W×D) mm 266×1,106×751 266×1,106×751
Weight kg 25 25
Gross Weight kg 31 31
Operation
Sound
H/M/L/SL dBA 35/33/31/29 35/33/31/29
External Static Pressure Pa 40 40
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Drawing No. 3D046065A 3D046066A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model CDKS50CVMB CDKS60CVMB
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color
——
Air Flow Rates
m³/min
(cfm)
H 12.0 (424) 16.0 (565)
M 11.0 (388) 14.8 (523)
L 10.0 (353) 13.5 (477)
SL 8.4 (297) 11.2 (395)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 130 130
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.64 0.74
Power Consumption (Rated) W 140 160
Power Factor % 95.1 94.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 200×900×620 200×1,100×620
Packaged Dimensions (H×W×D) mm 266×1,106×751 266×1,306×751
Weight kg 27 30
Gross Weight kg 34 37
Operation
Sound
H/M/L/SL dBA 37/35/33/31 38/36/34/32
External Static Pressure Pa 40 40
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Drawing No. 3D046067A 3D046068A
