Specifications Si12-411A
36 Specifications
1.3 Indoor Units - Heat Pump
Wall Mounted Type
50Hz 220-230-240V / 60Hz 220-230V
Model
FTXE25BVMA FTXE35BVMA
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.8 (275) 8.1 (286) 7.7 (272) 8.1 (286)
M 6.4 (226) 6.6 (233) 6.3 (222) 6.6 (233)
L 5.0 (177) 5.1 (180) 4.9 (173) 5.1 (180)
SL 4.3 (152) 4.3 (152) 4.4 (155) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.17-0.18-0.18/0.21-0.21 0.17-0.18-0.18/0.21-0.21 0.17-0.18-0.18/0.21-0.21 0.17-0.18-0.18/0.21-0.21
Power Consumption (Rated) W 37-40-43/45-48 37-40-43/45-48 37-40-43/45-48 37-40-43/45-48
Power Factor % 98.9-96.6-99.5/97.4-99.4 98.9-96.6-99.5/97.4-99.4 98.9-96.6-99.5/97.4-99.4 98.9-96.6-99.5/97.4-99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 37/34/30/27 37/33/30/27 38/35/32/29 38/35/31/28
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D040689 3D040690
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FTXD50BVMA FTXD60BVMA
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 16.8 (593) 17.5 (618) 17.5 (618) 18.7 (660)
M 14.0 (494) 14.9 (526) 14.6 (515) 16.1 (568)
L 11.8 (417) 12.5 (441) 12.2 (431) 13.6 (480)
SL 10.4 (367) 11.0 (388) 10.8 (381) 11.8 (417)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17/0.19-0.18 0.19-0.18-0.17/0.19-0.18 0.21-0.20-0.19/0.21-0.20 0.21-0.20-0.19/0.21-0.20
Power Consumption (Rated) W 40 40 45 45
Power Factor % 95.7-96.6-98.0/95.7-96.6 95.7-96.6-98.0/95.7-96.6 97.4-97.8-98.7/97.4-97.8 97.4-97.8-98.7/97.4-97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D040790 3D040791
