Daikin CDKD35CVM User Manual

Si12-411A Specifications
Specifications 35
50Hz, 230V
Notes:
1. The data are based on the conditions shown in the table below.
Model 4MKS75BVMB 4MKS90BVMB
Cooling Capacity
kW
——
Power Consumption
W
——
Running Current
A
——
Casing Color Ivory White Pale Ivory
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC45BXD 2YC45BXD
Motor Output W 1,380 1,380
Refrigerant Oil
Model FVC50K FVC50K
Charge L 0.75 0.75
Refrigerant
Type R410A R410A
Charge kg 2.3 3.1
Air Flow Rates
m³/min
H 51 48.5
L45 42
cfm
H 1,472 1,400
L 1,299 1,212
Fan
Type Propeller Propeller
Motor Output W 53 51
Running Current A H: 0.33 / L: 0.25 H: 0.44 / L: 0.34
Power Consumption W H: 68 / L: 46 H: 60 / L: 41
Starting Current A 8.7 9.1
Dimensions (H×W×D) mm 735×936×300 908×900×320
Packaged Dimensions (H×W×D) mm 784×960×357 942×926×394
Weight kg 58 66
Gross Weight kg 62 77
Operation Sound dBA 48 48
Sound Power dBA 61 61
Piping Connection
Liquid mm
φ
6.4
×
4
φ
6.4
×
4
Gas mm
φ
9.5
×
2,
φ
12.7
×
1,
φ
15.9
×
1
φ
9.5
×
1,
φ
12.7
×
1,
φ
15.9
×
2
Drain mm
φ
18.0
φ
25.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 60 (for Total of Each Room) 70 (for Total of Each Room)
m 25 (for One Room) 25 (for One Room)
Amount of Additional Charge g/m Chargeless Chargeless
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D039606#1 3D039608#1
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
7.5m
