Specifications Si12-411A
46 Specifications
Floor / Ceiling Suspended Dual Type
50Hz 220-230-240V / 60Hz 220-230V
Model
FLX25AVMA FLX35AVMA
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 7.6 (268) 9.2 (325) 8.7 (307) 10.0 (353)
M 6.8 (240) 8.3 (293) 7.7 (272) 9.0 (318)
L 6.0 (212) 7.4 (261) 6.6 (233) 8.0 (282)
SL 5.2 (184) 6.6 (233) 5.6 (198) 7.1 (251)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.32-0.32-0.32/0.34-0.34 0.34-0.34-0.34/0.37-0.37 0.36-0.36-0.36/0.39-0.39 0.36-0.36-0.36/0.39-0.39
Power Consumption (Rated) W 68-70-72/72-74 72-74-76/76-79 76-78-80/80-84 76-78-80/80-83
Power Factor % 96.6-95.1-93.8/96.3-94.6 96.3-94.6-93.1/93.4-92.8 96.0-94.2-92.6/93.2-93.6 96.0-94.2-92.6/93.2-92.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Packaged Dimensions (H×W×D) mm 280×1,100×566 280×1,100×566
Weight kg 16 16
Gross Weight kg 22 22
Operation
Sound
H/M/L/SL dBA 37/34/31/28 37/34/31/28 38/35/32/29 39/36/33/30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D036690 3D036691
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FLX50AVMA FLX60AVMA
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 5.7kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 12.1 (427) 12.0 (424) 12.8 (452)
M 10.0 (353) 9.8 (346) 10.6 (374) 10.6 (374)
L 8.5 (300) 7.5 (265) 9.3 (328) 8.4 (297)
SL 7.5 (265) 6.8 (240) 8.3 (293) 7.5 (265)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.45-0.45-0.45/0.48-0.48 0.45-0.45-0.45/0.48-0.48 0.47-0.47-0.47/0.51-0.51 0.45-0.45-0.45/0.48-0.48
Power Consumption (Rated) W 94-96-98/98-100 94-96-98/98-100 96-98-100/100-104 94-96-98/98-101
Power Factor % 94.9-92.8-90.7/92.8-90.6 94.9-92.8-90.7/92.8-90.6 92.8-90.7-88.7/89.1-88.7 94.9-92.8-90.7/92.8-91.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 490×1,050×200 490×1,050×200
Packaged Dimensions (H×W×D) mm 280×1,100×566 280×1,100×566
Weight kg 17 17
Gross Weight kg 24 24
Operation
Sound
H/M/L/SL dBA 47/43/39/36 46/41/35/32 48/45/41/38 47/42/37/34
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D036692 3D036693
