Specifications Si12-411A
52 Specifications
50Hz 230V
Notes:
1. The data are based on the conditions shown in the table below.
Model
3MXS52BVMB(8) 4MXS68BVMB9
Cooling Heating Cooling Heating
Cooling Capacity kW
——
Power Consumption W
——
Running Current A
——
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32HXD 2YC45BXD
Motor Output W 980 1,380
Refrigerant Oil
Model FVC50K FVC50K
Charge L 0.65 0.75
Refrigerant
Type R410A R410A
Charge kg 2.0 2.6
Air Flow Rates
m³/min
H 44 44 51 47.6
L37374545
cfm
H 1,270 1,270 1,472 1,374
L 1,068 1,068 1,299 1,299
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current A H: 0.24 / L: 0.17 H: 0.33 / L: 0.25
Power Consumption W H: 44 / L: 27 H: 68 / L: 46
Starting Current A 6.9 8.5
Dimensions (H×W×D) mm 735×936×300 735×936×300
Packaged Dimensions (H×W×D) mm 784×960×357 784×960×357
Weight kg 55 59
Gross Weight kg 59 63
Operation Sound dBA 46 47 48 49
Sound Power dBA 59 60 61 62
Piping Connection
Liquid mm
φ
6.4
×
3
φ
6.4
×
4
Gas mm
φ
9.5
×
2
, φ
12.7
×
1
φ
9.5
×
2
, φ
12.7
×
2
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 45 (for Total of Each Room) 60 (for Total of Each Room)
m 25 (for One Room) 25 (for One Room)
Amount of Additional Charge g/m 20 (30m or more) 20 (30m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D039603#1 3D039604#1
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
