SYSTEM OPERATION
12
Indoor
Coil
Accumulator
Outdoor
Coil
Reversing Valve
(Energized)
Indoor
Coil
Accumulator
Outdoor
Coil
Reversing Valve
(De-Energized)
DCH***XXX**XXX
Typical Package Heat Pump
COOLING CYCLE
HEATING CYCLE
