Daikin DPS020 - Page 11

Table 2: Physical Data—Unit Weights DPS 003 through 028
Model
Small Cabinet Medium Cabinet
003 004 005 006 007 010 012 015
Weight (lbs.)
Base Weight
1
1000 1000 1025 1058 1600 1600 1600 1763
Heat pump 1030 1030 1058 1058 1660 1660 1660 1823
Electric Heat 45 45 45 45 100 100 100 100
Hot Water 2 Row 11 11 11 16.5 30 30 30 30
Hot Water 1 Row 32 32 32 20 31 31 31 31
Gas Heat 75 75 63 93 186 186 186 186
Hot Gas Re-heat 8 8 12 12 28 31 31 31
Economizer 163 163 163 163 308 308 308 308
High capacity coil 105 105 105 105 215 215 215 215
Energy Wheel Weight Adds (lbs.)
100% OA 160 160 160 160 300 300 300 300
Mixed Air 175 175 175 175 250 250 250 250
1. Includes standard cooling coil
Model
Large Cabinet
016 018 020 025 028
Base Weight (in lbs.) 2,465 2,575 2,700
Heat Pump — — — — —
Electric Heat 228
Hot Water Heat
1-row 60
2-row 100
3-row 140
Gas Heat
300 175
450 225
600 275
Hot Gas Reheat 30
Economizer 500
ERW – Small 350
ERW – Large 400
Indoor Fan
16" 100
20" 150
24" 260
Indoor Fan Motors
1 36
1.5 41
2 40
3 69
5 84
7.5 115
10 128
15 211
20 225
Exhaust Fan 250
Size 3–15 Fan Weights (lbs.)
12 (in) 87
14 (in) 91
16 (in) 115
18 (in) 87
20 (in) 91
22 (in) 115
Curb Weights (lbs.) 14" 24"
003—006 156 230
007—015 200 295
016—028 566 657
Table 3: Refrigerant Charge
Unit Size
Cooling Model Heat Pump Model
Standard Unit
Standard Unit
w/ MHGRH
Standard Unit
Standard Unit
w/ MHGRH
3 10.5 12.9 12.0 14.4
4 11.1 13.5 12.6 15.0
5 15.3 18.2 16.8 19.7
6 15.3 18.2 16.8 19.7
7.5 11.0 17.3 26.0 31.2
10 34.0 39.8 40.0 45.8
12 34.0 39.8 40.0 45.8
15 37.0 43.8 42.0 47.8
16 37.0
Consult Factory
18 37.0
20 37.0
25 35.5
28 35.5
MeChanICal InsTallaTIon
www.DaikinApplied.com 11 IM 1125-7 • REBEL ROOFTOPS
