Daikin DZ9VC - 7-Segment Display Settings (Mode 2); Setting Mode 2 Configurations

31
SCREEN 4 (SETTING MODE 2)

Screen 4
Setting No.
Contents
Setting
Installer/Serviceman Notes
1
Maximum Defrost Interval
0: 30min.
1: 60min.
2: 90min.
3: 120min.
2
Set Maximum Current
N/A
Future Use
4
System Verification Test (System Test)
0: ON 1: OFF
7
Force Defrost Cycle
0: ON 1: OFF
8
Pump Down
0: ON 1: OFF
9
Charge Mode
0: ON 1: OFF
10
Maximum Compressor RPS for Cooling
*
11
Maximum Compressor RPS for Heating
*
12
BOOST MODE Selection
0: ON 1: OFF
13
BOOST MODE Temperature
0:105F, 1:100F, 2:95F,
3:90F, 4:85F, 5:80F, 6:75F,
7:70F, 8:Always ON
* Depends on tonnage. Can adjust compressor RPS in each 0.5 RPS.
NOTE: Parameters as per factory setting are highlighted in bold and underlined.
