4 | About the box
Installer reference guide
22
ERGA04~08EA + EHVH04+08SU18+23EA
Daikin Altherma 3 R F
4P629090-1A – 2021.11
4 About the box
INFORMATION
This unit is a heating only model. Therefore, all references to cooling in this
document are NOT applicable.
In this chapter
4.1 Overview: About the box........................................................................................................................................................ 22
4.2 Outdoor unit ........................................................................................................................................................................... 23
4.2.1 To unpack the outdoor unit ................................................................................................................................... 23
4.2.2 To handle the outdoor unit.................................................................................................................................... 23
4.2.3 To remove the accessories from the outdoor unit ............................................................................................... 24
4.3 Indoor unit .............................................................................................................................................................................. 24
4.3.1 To unpack the indoor unit...................................................................................................................................... 25
4.3.2 To remove the accessories from the indoor unit.................................................................................................. 25
4.3.3 To handle the indoor unit ...................................................................................................................................... 25
4.4 Domestic hot water tank kit ................................................................................................................................................... 26
4.4.1 To remove the accessories from the domestic hot water tank kit ....................................................................... 26
4.5 Checklist for the required DHW accessories.......................................................................................................................... 26
4.1 Overview: About the box
This chapter describes what you have to do after the boxes with the outdoor and
indoor unit are delivered on-site.
Keep the following in mind:
▪ At delivery, the unit MUST be checked for damage. Any damage MUST be
reported immediately to the claims agent of the carrier.
▪ Bring the packed unit as close as possible to its final installation position to
prevent damage during transport.
▪ Prepare the path along which you want to bring the unit inside in advance.
