ESIE10-01 Functional Control
Part 2 – Functional Description 2–51
3
2
4
5
1
2.3.7 Liquid Injection
Liquid injection shall be activated when the circuit is in a run state and the discharge temperature rises
above the Liquid Injection Activation set point.
Liquid injection should be turned off when the discharge temperature decreases below the activation
set point by a differential of 10°C.
Liq. Inj. ON
75°C 85°C
Liq. Inj. OFF
(del Temp.) Oil Temp.
To Next Page
