1.15 Electrical Specifications: EWAD~C-SL
Electrical
specifications
The table below contains the electrical specifications
Model EWAD~C-SL
650 740 830 910 970
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 628.4 665.2 665.2 904.2 949.8
Nominal running current cooling A 365 432 492 523 574
Maximum running current A 486 532 578 643 700
Maximum current for wires sizing A 535 585 636 707 770
Fans Nominal running current in cooling A 40 40 40 48 48
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 223+223 223+269 269+269 269+326 326+326
Starting Method Wye - Delta type (Y -Δ)
Model EWAD~C-SL
C11 C12 C14 C15 C16 C17
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 1009 1017 1242.6 1293.8 1353 1353
Nominal running current cooling A 624 668 823 908 959 1023
Maximum running current A 772 844 1058 1122 1194 1258
Maximum current for wires sizing A 849 928 1164 1234 1313 1384
Fans Nominal running current in cooling A 56 64 80 80 88 88
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 326+390 390+390 326+326
+326
390+326
+326
390+390
+326
390+390
+390
Starting Method Wye - Delta type (Y -Δ)
