General Outline ESIE10-01
1–44 Part 1 – System Outline
3
11
4
5
1.16 Electrical Specifications: EWAD~C-SR
Electrical
specifications
The table below contains the electrical specifications
Model EWAD~C-SR
620 720 790 880 920
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 614.4 651.2 651.2 887.4 933
Nominal running current cooling A 370 449 518 546 606
Maximum running current A 472 518 564 626 683
Maximum current for wires sizing A 519 570 620 689 752
Fans Nominal running current in cooling A 26 26 26 31 31
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 223+223 223+269 269+269 269+326 326+326
Starting Method Wye - Delta type (Y -Δ)
Model EWAD~C-SR
C10 C11 C13 C14 C15 C16
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 989.4 994.6 1214.6 1265.8 1322.2 1322.2
Nominal running current cooling A 653 694 853 951 1001 1074
Maximum running current A 752 822 1030 1094 1163 1227
Maximum current for wires sizing A 828 904 1133 1203 1280 1350
Fans Nominal running current in cooling A 36 42 52 52 57 57
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 326+390 390+390 326+326
+326
390+326
+326
390+390
+326
390+390
+390
Starting Method Wye - Delta type (Y -Δ)
