ESIE10-01 General Outline
Part 1 – System Outline 1–49
3
1
4
5
1.19 Electrical Specifications: EWAD~C-XR
Electrical
specifications
The table below contains the electrical specifications.
Model EWAD~C-XR
740 810 870 970
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 619.6 661.6 661.6 897.8
Nominal running current cooling A 391 425 470 517
Maximum running current A 477 528 574 637
Maximum current for wires sizing A 525 581 632 700
Fans Nominal running current in cooling A 31 36 36 42
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 223+223 223+269 269+269 269+326
Starting Method Wye - Delta type (Y -Δ)
Model EWAD~C-XR
C10 C11 C12 C13 C14
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 943.4 1005 1005 1005 1133.8
Nominal running current cooling A 570 613 679 697 734
Maximum running current A 694 768 832 832 926
Maximum current for wires sizing A 763 845 915 915 1019
Fans Nominal running current in cooling A 42 52 52 52 62
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 326+326 326+390 390+390 390+390 269+269
+326
Starting Method Wye - Delta type (Y -Δ)
