General Outline ESIE10-01
1–50 Part 1 – System Outline
3
11
4
5
Model EWAD~C-XR
C15C16C17C18C19
Power Supply Phase 3
Frequency Hz 50
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Unit Maximum starting current A 1179.4 1225 1281.4 1337.8 1343
Nominal running current cooling A 799 851 901 950 1001
Maximum running current A 983 1040 1110 1179 1248
Maximum current for wires sizing A 1082 1144 1221 1297 1373
Fans Nominal running current in cooling A 62 62 68 73 78
Compressor Phase No. 3
Voltage V 400
Voltage Tolerance Minimum % -10%
Maximum % +10%
Maximum running current A 326+326
+269
326+326
+326
326+326
+390
390+390
+326
390+390
+390
Starting Method Wye - Delta type (Y -Δ)
