1.28 Heat Recovery Ratings
Water Pump Kit -
Combination Matrix
Water Pump Kit -
Technical
Information
Notes: When using mixture of water and glycol please contact the factory as above specification can change.
Single Pump Double Pump
Version Size SPK1 SPK2 SPK3 DPK1 DPK2 DPK3 DPK4
EWAD~C-SS
EWAD~C-SL
EWAD~C-SR
650 X X X X X
740 X X X X X
830 X X X X X
910 X X X X X
970XXXXXXX
C11XXXXXXX
C12XXXXXXX
EWAD~C-XS
EWAD~C-XL
EWAD~C-XR
760 X X X X X
830 X X X X X
890 X X X X X
990XXXXXXX
C10XXXXXXX
C11XXX XXX
C12XXX XXX
C13XXX XXX
EWAD~C-PS
EWAD~C-PL
EWAD~C-PR
820 X X X X X
890 X X X X X
980XXXXXXX
C11XXXXXXX
C12XXX XXX
C13XXX XXX
C14 XX XXX
Pump Motor
Power (kW)
Pump Motor
Current (A)
Power Supply
(V-ph-Hz)
PN
Motor
Protection
Insulation
(Class)
Working
Temp. (°C)
Single
Pump
SPK1 11.0 20.0 400V-3ph-50hz 16 IP55 class F -20 +140
SPK2 15.0 26.5 400V-3ph-50hz 16 IP55 class F -20 +140
SPK3 18.5 32.5 400V-3ph-50hz 16 IP55 class F -20 +140
Double
Pump
DPK1 11.0 20.0 400V-3ph-50hz 16 IP55 class F -20 +140
DPK2 15.0 26.5 400V-3ph-50hz 16 IP55 class F -20 +140
DPK3 18.5 32.5 400V-3ph-50hz 16 IP55 class F -20 +140
DPK4 22.0 39.0 400V-3ph-50hz 16 IP55 class F -20 +140
