General Outline ESIE10-01
1–80 Part 1 – System Outline
3
11
4
5
1.29 Evaporator Pressure Drops
EWAD~C-SS
EWAD~C-SL
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C –
condenser air inlet: 35°C.
EWAD~C-SR
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C –
condenser air inlet: 35°C.
EWAD~C-XS
EWAD~C-XL
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C –
condenser air inlet: 35°C.
EWAD~C-XR
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C –
condenser air inlet: 35°C.
650 740 830 910 970 C11 C12 C14 C15 C16 C17
Cooling Capacity (kW) 647 744 832 912 967 1064 1152 1419 1538 1622 1714
Water Flow (l/s) 30.90 35.56 39.74 43.60 46.21 50.85 55.04 67.78 73.5 77.51 81.89
Pressure Drops (kPa) 7359526168637247596573
650 740 830 910 970 C11 C12 C14 C15 C16 C17
Cooling Capacity (kW) 619 715 789 876 922 1020 1112 1367 1471 1556 1623
Water Flow (l/s) 29.57 34.15 37.71 41.83 44.05 48.75 53.11 65.32 70.28 74.32 77.57
Pressure Drops (kPa) 6755475762586844546066
760 830 890 990 C10 C11 C12 C13 C14 C15 C16 C17 C18 C19
Cooling Capacity
(kW)
756 830 889 1001 1074 1196 1280 1349 1409 1526 1596 1685 1768 1858
Water Flow (l/s) 36.10 39.67 42.49 47.82 51.32 57.13 61.18 64.45 67.34 72.90 76.24 80.48 84.47 88.79
Pressure Drops
(kPa)
80 56 64 61 69 45 51 71 77 57 62 68 64 37
760 830 890 990 C10 C11 C12 C13 C14 C15 C16 C17 C18 C19
Cooling Capacity
(kW)
736 811 866 974 1041 1168 1247 1302 1378 1486 1550 1639 1722 1813
Water Flow (l/s) 35.17 38.74 41.36 46.54 49.76 55.78 59.56 62.21 65.85 70.98 74.07 78.32 82.3 86.61
Pressure Drops
(kPa)
76 54 61 58 65 43 49 67 74 54 59 65 61 35
