General Outline ESIE10-01
1–84 Part 1 – System Outline
3
11
4
5
1.31 Operation Range
EWAD~C-
Evaporator
minimum and
maximum water Δt
Standard Efficiency
Evaporator Leaving Water Temp. (°C)
High Efficiency Premium Efficiency
Condenser Inlet Air Temp. (°C)
Operation with Glycol
(below 4°C Evap LWT)
Fan Speed Regulation required
(below 10°C Amb. Temp)
Speedtroll required (below -10°C Amb. Temp)
Max evaporator water Δt
°C 8
Min evaporator water
Δt
°C 4
